RH-AUDIO Waterproof Ceiling Speaker RH-TWF23

※ IP55 waterproof ceiling speaker.
※ 100v line voltage transformer.
※ Rated power 3W/6W.
※ Spring clamps.
  • Description
  • Specification
This water-resistant ceiling speaker RH-TWF23 is specially made for damp environments,built-in 100v transformer with a length of wiring for easy connection, can be used in bathrooms,outside under the porch and on ships etc.


Installation Illustration:

RH-AUDIO Waterproof Ceiling Speaker RH-TWF23 Installation Illustration

Specifications of RH-AUDIO Waterproof Ceiling Speaker RH-TWF23

RH-AUDIO Waterproof Ceiling Speaker RH-TWF23 Size

Model

RH-TWF23

Type

Waterproof IP55

Speaker Driver

4"

Power Handling Rate

3W/6W, 100V line transformer

Line Input

70V/100V

Sensitivity(1w,1m)

91±3dB

Frequency Response

150Hz-18Khz

Installation

spring wire terminals

Dimensions

Ø140*130mm

Cutting Hole

Ø125mm

Finish

ABS white

Net Weight

1.80Kg
