Unidirectional Sound Projector Loudspeaker RH-CH07

※ Unidirectional speaker driver: full range 6.5"*1.
※ With rated power taps: 5W / 10W / 20W.
※ Built-in 100V transformer.
※ ABS enclosure,metal grille and mounting bracket.
※ Easy and secure through the adjustable U shaped mounting bracket.
  • Description
  • Specification

Descriptionsof Unidirectional Sound Projector Loudspeaker RH-CH07

The RH-AUDIOUnidirectional Sound Projector Loudspeaker RH-CH07 is made with ABS housing,aluminum alloy grille and bracket, are fully antirust, dustproof and weatherproof IP65 rated and the speaker driver unit inside also are waterproof featured.

Built-in transformer with a length of connection cable at power 5W/10/20W,easily secured and installed through the adjustable U shaped mounting bracket.

The projector speakers are used commonly for corridors, tunnels, or any narrow areas which require a more projection sound dispersion.



Specifications of Unidirectional Sound Projector Loudspeaker RH-CH07

RH-AUDIOUnidirectional Sound Projector Loudspeaker RH-CH07 Size

Model

RH-CH07

Rated Power

5W/10W/20W

Input Voltage

100V

Frequency Response

110Hz-15KHz

Sensitivity(1w,1n)

92±3 dB

Dimension

Φ170*245mm

Finished

White

Material

ABS enclosure, metal grille and bracket

Speaker Driver

Waterproof 6.5"*1

Net Weight

1.8kg

IP Rating

IP65
